| Element | % Present |
| Si | 0.50 – 0.90 |
| Fe | 0.0 – 0.50 |
| Cu | 3.90 – 5.00 |
| Zn | 0.0 – 0.25 |
| Mn | 0.40 – 1.20 |
| Mg | 0.20 – 0.80 |
| Ti | 0.0 – 0.15 |
| Cr | 0.0 – 0.10 |
| Ni | 0.0 – 0.10 |
| Ti+Zr | 0.0 – 0.20 |
| Al | Balance |
| Others (Total) | 0.0 – 0.15 |
| Other (Each) | 0.0 – 0.05 |
Aluminium 2014 T6 Round Bars Physical Properties
| Physical Property | Value |
| Density | 2.82 g/cm³ |
| Melting Point | 535 °C |
| Modulus of Elasticity | 71 GPa |
| Electrical Resistivity | 0.045 x10^-6 Ω .m |
| Thermal Conductivity | 138 W/m.K |
| Thermal Expansion | 23 x10^-6 /K |
AA2014-T651 Round Bars Mechanical Properties
| Element | Aluminium 2014 T6 |
| Tensile Yield Strength | 60000 psi |
| Ultimate Tensile Strength | 70000 psi |
| Modulus of Elasticity | 10500 ksi |
| Elongation % | 13 % |
| Hardness | 155 |
Standard Specification of 2014 T6 Aluminium Round Bar
| Specification | Alloy | Temper | Company |
| Europe | |||
| EN 2089/2395 | 2014A | T6(T62)/T4(T42) | |
| EN 2087/2088 | 2014A clad | T6(T62)/T4(T42) | |
| France | |||
| AIR 9048.010/.030/ | 2014 | F(T42)/F(T62)/T4/ | |
| .020/.040/.050 | 2014 | T6/T451 | |
| AIR 9048.060/.080/.070/.090 | 2014 clad | F(T42)/F(T62)/T4/T6 | |
| Germany | |||
| W.-Nr. 3.1254 | 2014A | T4, T6 | |
| W.-Nr. 3.1354 | 2024 | O(T42), T3 | |
| United Kingdom | |||
| BS L156/157/158*/159* | 2014A | ||
| 158*/159* | 2014A clad | (T42)(T62) | BAE Systems |
| BS L163/164/165 | 2014A clad | T3/F(T42), T4/T6 | |
| BS L166*/167* | 2014A clad | F(T42), T4/T6 | |
| USA | |||
| AMS QQ-A-250/3 | 2014 clad | O, T4, T6 | |
| Applications | Aerospace, Automotive, Chemical Packaging, Construction, Decorative/Architectural, Defense, Electronics, Food & Packaging, General Fabrication, HVAC & Heat Exchangers, Industrial Equipment, Industrial Machinery, Marine Industry, Transportation |
|---|---|
| Primary Alloying Element | 99%+ Pure Aluminum, Copper (Cu), Magnesium (Mg), Magnesium + Silicon (Mg+Si), Manganese (Mn), Other elements (e.g., Li), Silicon (Si), Zinc (Zn) |
| Key Properties | Corrosion Resistance, Excellent Thermal Conductivity, Heat-Treatable, High Electrical Conductivity, High Formability, High Strength, Low Strength, Moderate Conductivity, Moderate Strength, Non-Heat-Treatable, Poor Corrosion Resistance, Soft & Ductile, Ultra-High Strength, Weldable |
